Silicone Wire UL3512 Fine Gauge 22 AWG — 200°C, 600V
Part No. SW-UL3512-22-500
Fine gauge silicone wire for electronics, LED lighting, and low current high-temperature applications.
- Conductor
- 22 AWG
- Voltage
- 600V
- Temp
- 200°C
- Ampacity
- 7A @ 200°C
Color: 10+ Colors Available
- MOQ
- 1,000 ft (305 m)
- Ships in
- 3-5 business days
- Packaging
- 1000 ft Reels
Made at our Kunshan factory. Need a custom build, private label or DDP delivery? See our cable manufacturing services.
Silicone Wire UL3512 Fine Gauge specifications
| Conductor | Tinned Copper Ultra-Fine Stranded |
|---|---|
| Insulation | Premium Silicone Rubber |
| Gauge | 22 AWG |
| Voltage Rating | 600V |
| Temperature Rating | 200°C |
| Ampacity | 7A @ 200°C |
| Color | 10+ Colors Available |
| Packaging | 1000 ft Reels |
Compare with similar
| Wire | Max °C | Best for |
|---|---|---|
| Silicone Wire UL3512 Fine Gauge this product | 200°C | LED lighting, Electronic equipment |
| Silicone Wire UL AWM 3132 | 150°C | Appliance internal wiring, Heating equipment |
| Silicone Rubber Wire AGG Type | 180°C | Industrial automation, Robotics |
| PTFE Wire AF250 High Temperature | 250°C | Aerospace, Military |
Sizes in Silicone Rubber Wire
Each row is a separate construction with its own page and part number.
| AWG | Type | Part no. | Ampacity | Quote |
|---|---|---|---|---|
| 22 AWG | UL3512 | SW-UL3512-22-500 | 7A @ 200°C | Quote SW-UL3512-22-500 |
| 20 AWG, Silicone Rubber Wire AGG Type | AGG | SW-AGG-20-500 | 11A @ 180°C | Quote SW-AGG-20-500 |
| 18 AWG, Silicone Rubber Wire AGR Type | AGR | SW-AGR-18-500 | 10A @ 200°C | Quote SW-AGR-18-500 |
| 18 AWG, Silicone Wire JG Type Flexible | JG | SW-JG-18-500 | 10A @ 180°C | Quote SW-JG-18-500 |
| 18 AWG, Silicone Wire JGG Fiberglass Braided | JGG | SW-JGG-18-500 | 10A @ 180°C | Quote SW-JGG-18-500 |
| 16 AWG, Silicone Wire JHXG 1140V High Voltage | JHXG | SW-JHXG-16-1140V | 15A @ 180°C | Quote SW-JHXG-16-1140V |
| 16 AWG, Silicone Wire UL AWM 3132 | UL3132 | SW-UL3132-16-500 | 13A @ 150°C | Quote SW-UL3132-16-500 |
| 14 AWG, Silicone Wire UL AWM 3135 | UL3135 | SW-UL3135-14-500 | 18A @ 200°C | Quote SW-UL3135-14-500 |
22 AWG UL3512
this page- Part no.
- SW-UL3512-22-500
- Ampacity
- 7A @ 200°C
- Part no.
- SW-AGG-20-500
- Ampacity
- 11A @ 180°C
- Part no.
- SW-AGR-18-500
- Ampacity
- 10A @ 200°C
- Part no.
- SW-JG-18-500
- Ampacity
- 10A @ 180°C
- Part no.
- SW-JGG-18-500
- Ampacity
- 10A @ 180°C
- Part no.
- SW-JHXG-16-1140V
- Ampacity
- 15A @ 180°C
- Part no.
- SW-UL3132-16-500
- Ampacity
- 13A @ 150°C
- Part no.
- SW-UL3135-14-500
- Ampacity
- 18A @ 200°C
Construction
- 1
Conductor
Tinned Copper Ultra-Fine Stranded, sized 22 AWG to deliver 7A of continuous ampacity.
- 2
Insulation
Premium Silicone Rubber, rated to 200°C and 600V.
Applications
- LED lighting
- Electronic equipment
- RC models
- Battery connections
- Solar panels
Standards: UL AWM 3512
Common questions
What is the minimum order quantity and lead time?
Minimum order quantity is 1,000 ft (305 m). In stock — typical lead time 3-5 business days. Large-volume and OEM programs may qualify for reduced minimums and blanket order pricing.
What certifications and documentation are provided?
This product carries UL AWM 3512, RoHS Compliant, REACH Compliant certifications and complies with UL AWM 3512. Every shipment includes a Certificate of Compliance. UL yellow cards, RoHS/REACH declarations, production test reports, and full batch traceability are available on request.
Can this cable be used outdoors or in extreme temperatures?
Rated 200°C. For outdoor or UV-exposed installations, specify the UV-resistant formulation. Beyond the rated temperature range, PTFE/FEP fluoropolymer (extreme heat and chemical exposure) or TPE (cold flex) constructions are available — contact us with your environmental parameters.
Do you offer custom lengths, colors, or configurations?
Yes. Custom colors (2,500 ft min), custom print legends, gauge changes, shielding, and multi-conductor assemblies are available. OEM programs with blanket orders can negotiate minimums below the standard threshold. Send requirements to support@shanghaiunicorncable.com.
