What is the minimum order quantity and lead time?

Minimum order quantity is 500 ft. In stock — typical lead time 2-4 business days. Large-volume and OEM programs may qualify for reduced minimums and blanket order pricing.

What certifications and documentation are provided?

This product carries UL Listed, CE Certified certifications and complies with UL 2517. Every shipment includes a Certificate of Compliance. UL yellow cards, RoHS/REACH declarations, production test reports, and full batch traceability are available on request.

Can this cable be used outdoors or in extreme temperatures?

Rated 80°C. For outdoor or UV-exposed installations, specify the UV-resistant formulation. Beyond the rated temperature range, silicone (high heat) or TPE (cold flex) alternatives are available — contact us with your environmental parameters.

Do you offer custom lengths, colors, or configurations?

Yes. Custom jacket colours (2,500 ft min), custom print legends, gauge changes, shielding, and multi-conductor assemblies are available. OEM programs with blanket orders can negotiate minimums below the standard threshold. Send requirements to engineering@shanghaiunicorncable.com.

Servo Control Cable 4-Conductor — Industrial Cable

UL Listed · CE Certified

In Stock

Back to Industrial CableIndustrial Cable

Servo Control Cable 4-Conductor

Part No. SW-SERVO-22-4C-500

Multi-conductor servo control cable for feedback and control signals in automation systems.

Conductor

22 AWG

Voltage

600V

Ampacity

3A per conductor

Temperature

80°C

100% Hipot Tested ISO 9001 Factory CoC Included Factory-Direct

Request a Quote Talk to an Engineer

Technical Specifications

Conductor	Tinned Copper Fine Strand
Insulation	PVC with Overall Foil Shield
Gauge	22 AWG
Voltage Rating	600V
Temperature Rating	80°C
Ampacity	3A per conductor
Color	Gray
Packaging	500 ft, 1000 ft Reels
Conductors	4

Construction

Conductor

Tinned Copper Fine Strand, sized 22 AWG to deliver 3A per conductor of continuous ampacity.

Insulation

PVC with Overall Foil Shield, rated to 80°C and 600V.

Outer Jacket

Integrated with the PVC with Overall Foil Shield system — sized to protect the 22 AWG conductor through 80°C thermal cycling in servo control.

Finished Dimensions

Gray jacket, supplied on 500 ft, 1000 ft Reels.

Applications

Servo control

Feedback systems

Encoders

Motion control

UL 2517

Common Questions

In Stock — Ships Today

Part Number

SW-SERVO-22-4C-500

Conductor

22 AWG

Voltage

600V

Ampacity

3A per conductor

Min. Order500 ft

Lead Time2-4 business days

Packaging500 ft, 1000 ft Reels
