What is the minimum order quantity and lead time?

Minimum order quantity is 500 ft. In stock — typical lead time 5-7 business days. Large-volume and OEM programs may qualify for reduced minimums and blanket order pricing.

What certifications and documentation are provided?

This product carries UL Listed, CSA Certified, MSHA Approved certifications and complies with ICEA S-75-381. Every shipment includes a Certificate of Compliance. UL yellow cards, RoHS/REACH declarations, production test reports, and full batch traceability are available on request.

Can this cable be used outdoors or in extreme temperatures?

Rated 90°C. For outdoor or UV-exposed installations, specify the UV-resistant formulation. Beyond the rated temperature range, silicone (high heat) or TPE (cold flex) alternatives are available — contact us with your environmental parameters.

Do you offer custom lengths, colors, or configurations?

Yes. Custom jacket colours (2,500 ft min), custom print legends, gauge changes, shielding, and multi-conductor assemblies are available. OEM programs with blanket orders can negotiate minimums below the standard threshold. Send requirements to engineering@shanghaiunicorncable.com.

Mobile Crane Cable 6kV — Industrial Cable

UL Listed · CSA Certified · MSHA Approved

In Stock

Back to Industrial CableIndustrial Cable

Mobile Crane Cable 6kV

Part No. SW-MOBCRAN-6KV-500

Heavy-duty cable for mobile cranes and portable equipment with excellent abrasion resistance.

Conductor

1/0 AWG

Voltage

6kV

Ampacity

230A

Temperature

90°C

100% Hipot Tested ISO 9001 Factory CoC Included Factory-Direct

Request a Quote Talk to an Engineer

Technical Specifications

Conductor	Class B Stranded Copper
Insulation	EPR with CPE Jacket
Gauge	1/0 AWG
Voltage Rating	6kV
Temperature Rating	90°C
Ampacity	230A
Color	Black
Packaging	500 ft, 1000 ft Reels

Construction

Conductor

Class B Stranded Copper, sized 1/0 AWG to deliver 230A of continuous ampacity.

Insulation

EPR with CPE Jacket, rated to 90°C and 6kV.

Outer Jacket

Integrated with the EPR with CPE Jacket system — sized to protect the 1/0 AWG conductor through 90°C thermal cycling in mobile cranes.

Finished Dimensions

Black jacket, supplied on 500 ft, 1000 ft Reels.

Applications

Mobile cranes

Portable equipment

Construction machinery

ICEA S-75-381

Common Questions

In Stock — Ships Today

Part Number

SW-MOBCRAN-6KV-500

Conductor

1/0 AWG

Voltage

6kV

Ampacity

230A

Min. Order500 ft

Lead Time5-7 business days

Packaging500 ft, 1000 ft Reels
