Extreme Temperature Cable 250°C
Part No. SW-EXTTEMP-10-250
High-temperature cable rated for extreme heat applications up to 250°C.
Conductor
10 AWG
Voltage
600V
Ampacity
35A @ 250°C
Temperature
250°C
- Min. Order
- 500 ft
- Lead Time
- 7-10 business days
- Packaging
- 500 ft Reels
Technical Specifications
| Conductor | Nickel-Coated Stranded Copper |
| Insulation | Silicone Rubber with Fiberglass Braid |
| Gauge | 10 AWG |
| Voltage Rating | 600V |
| Temperature Rating | 250°C |
| Ampacity | 35A @ 250°C |
| Color | Red |
| Packaging | 500 ft Reels |
Construction
Conductor
Nickel-Coated Stranded Copper, sized 10 AWG to deliver 35A of continuous ampacity.
Insulation
Silicone Rubber, rated to 250°C and 600V.
Overbraid
Fiberglass Braid
Finished Dimensions
Red braid, supplied on 500 ft Reels.
Applications
Common Questions
What is the minimum order quantity and lead time?
Minimum order quantity is 500 ft. In stock — typical lead time 7-10 business days. Large-volume and OEM programs may qualify for reduced minimums and blanket order pricing.
What certifications and documentation are provided?
This product carries UL Listed, CSA Certified, RoHS Compliant certifications. Every shipment includes a Certificate of Compliance. UL yellow cards, RoHS/REACH declarations, production test reports, and full batch traceability are available on request.
Can this cable be used outdoors or in extreme temperatures?
Rated 250°C. For outdoor or UV-exposed installations, specify the UV-resistant formulation. Beyond the rated temperature range, PTFE/FEP fluoropolymer (extreme heat and chemical exposure) or TPE (cold flex) constructions are available — contact us with your environmental parameters.
Do you offer custom lengths, colors, or configurations?
Yes. Custom colors (2,500 ft min), custom print legends, gauge changes, shielding, and multi-conductor assemblies are available. OEM programs with blanket orders can negotiate minimums below the standard threshold. Send requirements to engineering@shanghaiunicorncable.com.
