What is the minimum order quantity and lead time?

Minimum order quantity is 500 ft. In stock — typical lead time 3-5 business days. Large-volume and OEM programs may qualify for reduced minimums and blanket order pricing.

What certifications and documentation are provided?

This product carries UL Listed, CSA Certified, NEC Compliant certifications and complies with UL 1569, NFPA 70 (NEC), CSA C22.2. Every shipment includes a Certificate of Compliance. UL yellow cards, RoHS/REACH declarations, production test reports, and full batch traceability are available on request.

Can this cable be used outdoors or in extreme temperatures?

Rated 90°C. For outdoor or UV-exposed installations, specify the UV-resistant formulation. Beyond the rated temperature range, silicone (high heat) or TPE (cold flex) alternatives are available — contact us with your environmental parameters.

Do you offer custom lengths, colors, or configurations?

Yes. Custom jacket colours (2,500 ft min), custom print legends, gauge changes, shielding, and multi-conductor assemblies are available. OEM programs with blanket orders can negotiate minimums below the standard threshold. Send requirements to engineering@shanghaiunicorncable.com.

MC Cable 12/2 with Ground — Commercial Cable

UL Listed · CSA Certified · NEC Compliant

In Stock

Back to Commercial CableCommercial Cable

MC Cable 12/2 with Ground

Part No. SW-MC-12-2-G-500

Metal clad cable for commercial building installations and power distribution.

Conductor

12 AWG

Voltage

600V

Ampacity

25A

Temperature

90°C

100% Hipot Tested ISO 9001 Factory CoC Included Factory-Direct

Request a Quote Talk to an Engineer

Technical Specifications

Conductor	Stranded Copper
Insulation	XHHW-2 with Aluminum Armor
Gauge	12 AWG
Voltage Rating	600V
Temperature Rating	90°C
Ampacity	25A
Color	Gray Armor
Packaging	500 ft, 1000 ft Reels
Conductors	2 + Ground

Construction

Conductor

Stranded Copper, sized 12 AWG to deliver 25A of continuous ampacity.

Insulation

XHHW-2 with Aluminum Armor, rated to 90°C and 600V.

Outer Jacket

Integrated with the XHHW-2 with Aluminum Armor system — sized to protect the 12 AWG conductor through 90°C thermal cycling in office buildings.

Finished Dimensions

Gray Armor jacket, supplied on 500 ft, 1000 ft Reels.

Applications

Office buildings

Retail spaces

Healthcare facilities

Educational institutions

UL 1569NFPA 70 (NEC)CSA C22.2

Common Questions

In Stock — Ships Today

Part Number

SW-MC-12-2-G-500

Conductor

12 AWG

Voltage

600V

Ampacity

25A

Min. Order500 ft

Lead Time3-5 business days

Packaging500 ft, 1000 ft Reels

Request a Quote Talk to an Engineer
